ZQ-P8550 All in One POS System, 15 Inch (capacitive)

The ZQ-P8550 is a compact all-in-one POS system with an integrated 80 mm thermal printer built into the base. It combines touchscreen, terminal, and receipt printer in one robust, space-saving unit – ideal for professional checkout stations in retail, hospitality, and service-oriented POS environments.

Versatile. Compact. Ready to go.

The ZQ-P8550 is a robust all-in-one POS system designed for professional applications in retail, hospitality, and service-oriented checkout environments. Unlike the classic ZQ-T8550, the ZQ-P8550 features an integrated 80 mm thermal printer built into its base, combining terminal, touchscreen, and receipt printer in one space-saving unit.

The timeless aluminum housing with subtle plastic accents blends seamlessly into modern counter, checkout, and service environments. By integrating the printer, the ZQ-P8550 reduces visible cables, external peripherals, and counter space requirements – ideal for workspaces where a tidy setup, fast operation, and reliable receipt printing are essential.

Despite its compact all-in-one design, the POS system remains flexibly expandable. Optional additions include a Dallas lock, Addimat lock, external 2×20 VFD customer display, graphic customer displays, and an internal Wi-Fi module. A side-mounted USB service port, cable management in the base, and an easily swappable SSD support service-friendly daily operation.

Depending on requirements, the ZQ-P8550 is available with an energy-efficient Intel Celeron J6412 CPU and expandable memory. The fanless design, bezel-free display, and robust construction make the system a reliable solution for modern checkout stations with high demands on functionality, organization, and stability.

  • Brand
  • Reference
    ZQ-P8550

  • Kassenladen Anschluss
    1× RJ-11 Power Pin 12V or 24V
  • Dimensions
    230 × 350 × 400 mm (L × W × H)
  • Operating Conditions
    ~ -10 °C – ~ 40 °C
  • Storage Conditions
    ~ -20 °C – ~ 55 °C
  • Processor
    Intel® Celeron® Processor J6412
  • Graphics
    Intel UHD Graphics
  • RAM
    Standard 8 GB, optional up to 16 GB DDR4
  • Storage
    Standard 128 GB SSD, optional up to 512 GB
  • Display
    15" TFT LCD, 1024×768, 4:3
  • Touch
    Capacitive, 3-point standard
  • Interfaces
    1× COM, 1× VGA, 2× USB 3.0, 2× USB 2.0, 1× LAN (1000M), RJ-11/12, Audio Out
  • Power Supply
    24 V / 4 A external
  • Operating Systems
    Windows 11 compatible
  • Optional
    Dallas/Addimat lock, VFD 2×20, graphic customer displays (9.7", 13.3", 15", 15.6")
  • Peripherals Included
    80 mm thermal printer (80×80)
